HS-10dB 50W Directional Coupler with SMAF (2-8G)

Add to inquiry
DATASHEET
Product Specifications
PRODUCT SPECIFICATIONS
Frequency Range (Hz)
2~8G
VSWR (Max.)
1.3
Coupling
10dB±1.0dB
Insertion Loss dB(Max.)
1.0
Isolation dB(min.)
Amplitude Balance (Max.)
Phase Balance (Max.)
Power Handling
50W
Connector
SMA Female
