HS-Gain:32dB P1dB:13dBm NF:0.5dB Low Noise Amplifier With SMAF (0.8-1.6G)
Product Specifications
PRODUCT SPECIFICATIONS
Frequency Range (Hz)
0.8~1.6G
VSWR (dB Max.)
1.8
Gain (dB Min.)
27
Gain Flatness (dB Max.)
±1.0
DC Voltage (V DC)
6
Current (mA)
50
Connector
SMA Female
